2023/03/21
This is to inform that starting from April 1st, 2023 - HIWIN Torque Motor Rotary Table appearance color will be officially changed to dark grey.
2022/11/01
From May 1, 2023, some specifications of end-effector products will be discontinued.
2022/06/16
Considering the product function and application, from July 1, 2022, the product name will be officially changed to DATORKER Strain Wave Gear.
2022/07/07
CRG Series - High Rigidity Roller Type Linear Guideway with Cover Strip new product launch. Visit the product page on HIWIN website or click for reference.
2022/06/22
HIWIN EFEM Through effective control of dust generation and static suppression provides the clean environment required during the conveying process.
The advantage is on vertical integration of bothhardware and software, also using high precisionand stiffness DD motor, the repeatability can reach±0.1mm. Small circling radial and high utilizationof space.
2020/04/25
According to HIWIN product's value and development, we've decided to cease receiving Linear Bearing orders since February 28th, 2022.
2022/04/20
Newly Launched Ballscrew selection function. Please visit Hiwin website support page or click to enter.
2022/04/07
Newly Launched Product Selection Function of Single-Axis Robot. Visit the support page on HIWIN website or click to visit.
2022/01/11
HIWIN Robot Simulation software is a free download professional project planning application simulation software. Welcome to click to download it.
2021/10/26
2021 Linear Guideway Installation Instruction is launched. Please visit the technical support page on HIWIN website or click to download.
The download function interface of ballscrew drawing is updated. HIWIN technical support website also provides " Customized End Machining Design of the Shaft " selection function. Visit the support page on HIWIN website or click to download.
2021/10/20
Wafer robot add STP download file for 2 types of new forks, F262 &F275. User can download to use by themselves. Visit the technical support page on HIWIN website or to click below link to download.
2021/08/25
Easy to install the product without opening the stage cover. And higher performance:10~30% loading capacity increased.
2021/06/04
The Linear Guideway selection function allows you to find the product information you require according to the industry category.
2021/03/08
New 2D/3D drawing download function for Thin Type Crossed Roller Bearings
2021/02/09
The Robot communication manual is online. Visit the support page on HIWIN website or click to download.
2021/01/15
HIWIN i4.0BS Intelligent Ballscrew new product launch. Visit the product page on HIWIN website or click for reference.
2021/01/14
The Robot software program is online. Visit the support page on HIWIN website or click to download.
